Thermocouple Tips

Thermocouple tips for temperature measurement in demanding industrial environments.

• Type: Available in Platinum 10% S Type / Platinum 13% R Type
• Size: 300 mm to 1500 mm
• Connector Type: Male
• Application: Detect the temperature in slag condition
• Paper Tube: ID 18 mm / OD 30 mm
• Temperature Range: 0'C to 1750'C
• Used in: Foundry and Steel Plants

Sampler

Industrial sampler for high-temperature molten metal sampling applications.

• Temperature: 1580'C to 1720'C
• Shape: Round (41 mm x 32 mm)
• Size: 600 mm and 900 mm
• Paper Tube: ID 39 mm / OD 49 mm
• De-Oxidants: Zirconium and Aliminum

MTR

Thermocouple tip for temperature detection in slag-free conditions.

• Type: Available in Platinum 10% S Type / Platinum 13% R Type
• Size: 300 mm to 400 mm
• Connector Type: Male
• Application: Detect the temperature in slag free condition
• Paper Tube: ID 18 mm / OD 30 mm
• Used in: Foundry and Steel Plants

Receptacle Holder

Component support solution for temperature measurement assemblies.

Compensating Cable

Compensating cable for thermocouple signal connection and temperature measurement systems.
